IDEAL RAJ-7K Series User Manual

2
RAJ-7K-H & RAJ-7K-L
Jun 2022
TABLE OF CONTENTS
SPECIFICATIONS……………………………… 2
DESCRIPTION & FEATURES………………… 3
INSTALLATION INSTRUCTIONS…………….. 3
SAFETY INSTRUCTIONS…………………….. 4
OPERATING INSTRUCTIONS……………….. 4
MAINTENANCE INSTRUCTIONS……………. 5
TROUBLE SHOOTING………………………… 6
EXPLODED VIEW……………………………… 7
PARTS LIST…………………………………….. 8 - 9
LIMITED WARRANTY…………………………. 10
SPECIFICATIONS
Model Numbers: RAJ-7K-H & RAJ-7K-L
Max
Capacity
Size
L x W x H
*Height
(Min/Max)
Pad Width
(M
i
n/
Max)
Roller Body Asy
Width (Min/Max)
7,000 lbs. 34.25” x 37.8” x 8.7” 8.7” - 18.9” 29.1” - 51” 37.8” - 49.2”
* Height Adaptors not included
Net Weight: 300 lbs. / Gross Weight: 330 lbs.
Fig. 1

IDEAL RAJ-7K Series Specifications

General

Brand	IDEAL
Model	RAJ-7K Series
Category	Jacks
Language	English
