RAJ-7K-H & RAJ-7K-L
Jun 2022
PARTS LIST
ITEM
Tux P/N M-Ref P/N DESCRIPTION QTY
1 RAJ7K-001 LJ01-00007-000 Rubber Block 2
2 RAJ7K-002 LJ01-02000-000 Sliding Arm 2
3 RAJ7K-003 LJ01-08000-000 Arm Weldment 1
4 RAJ7K-004 LJ01-00005-000 Side Curtain 2
5 RAJ7K-005 LJ01-00004-000 Screw, M6 x 8mm 18
6 RAJ7K-006 LJ01-00009-000 Shaft #3 1
7 RAJ7K-007 LJ01-00001-000 Slide Block #1 4
8 RAJ7K-008 LJ01-00006-000 Slide Block #2 2
9 RAJ7K-009 LJ01-07000-000 Inner scissor 1
10 RAJ7K-010 LJ01-03000-000 Outer scissor 1
11 RAJ7K-011 5202-00010-000 Nut, M10 10
12 RAJ7K-012 5301-00010-000 Flat Washer, D10 18
13 RAJ7K-013 5101-10024-000 Bolt, M10 x 24mm 2
14 RAJ7K-014 LJ01-00011-000 Hydraulic Hose 1
15 RAJ7K-015 LJ01-00003-000 Threaded Pin, M6 x 10mm 2
16 RAJ7K-016 LJ01-00002-000 Shaft #1 1
17 RAJ7K-017 LJ01-04000-000 Hydraulic Cylinder 1
18 RAJ7K-018 LJ01-00012-000 Shaft #4 1
19 RAJ7K-019 LJ01-01100-001 Roller Body Frame 2
20 RAJ7K-020 LJ01-09000-000 Base Weldment 1
21 AP-10K QY030S-00 Air-Hydraulic Pump 1
22 RAJ7K-022 LJ01-06000-000 Safety Latch & Handle (A) 1
23 RAJ7K-023 5301-00016-000 Flat Washer, D16 2
24 RAJ7K-024 5202-00016-000 Nut, M16 2
25 RAJ7K-025 LJ01-05000-000 Safety Latch (B) 1
26 RAJ7K-026 LJ01-00008-000 Shaft #2 1
27 RAJ-H-SLDRASY
LJ04-01000-H00 (High Mount) Roller Body Assy.
2
29 RAJ-L-SLDRASY LJ04-02000-H00 (Low Mount) Roller Body Assy. 2
31 RAJ7K-031 5104-08016-000 Bolt, M8 x 16mm 4
