IDEAL RAJ-7K Series

9
RAJ-7K-H & RAJ-7K-L
Jun 2022
RAJ-7K-H (High Mount) Roller Body Assembly Parts (#27)
ITEM Tux P/N M-Ref P/N DESCRIPTION QTY
27-1 RAJ7K-027.1 5206-00006-000 Lock Nut, M6 8
27-2 RAJ7K-027.2 5301-00006-000 Flat Washer, D6 16
27-3 RAJ7K-027.3 LJ04-01001-000 Small, Side Bearing 8
27-4 RAJ7K-027.4 LJ04-01003-000
(High Mount)
RB Support Frame
2
27-5 RAJ7K-027.5 5104-06030-000 Bolt, M6 x 30mm 4
27-6 RAJ7K-027.6 5105-10030-000 Socket Head Bolt, M10 x 30mm 4
27-7 RAJ7K-027.7 LJ04-01002-000 Large, Wheel Bearing 8
27-8 RAJ7K-027.8 LJ04-01004-000 Spring Support Bar 2
27-9 RAJ7K-027.9 5206-00010-000 Lock Nut, M10 4
27-10 RAJ7K-027.10 5105-06016-000 Socket Head Bolt, M6 x 16mm 4
27-11 RAJ7K-027.11 LJ04-01005-000 Bushing 4
28 RAJ7K-028 5104-10035-000 Bolt, M10 x 35mm 8
RAJ-7K-L (Low Mount) Roller Body Assembly Parts (#29)
ITEM Tux P/N M-Ref P/N DESCRIPTION QTY
27-1 RAJ7K-027.1 5206-00006-000 Lock Nut, M6 4
27-2 RAJ7K-027.2 5301-00006-000 Flat Washer, D6 16
27-3 RAJ7K-027.3 LJ04-01001-000 Small, Side Bearing 8
29-4 RAJ7K-029.4 LJ04-02001-000
(Low Mount)
RB Support Frame
2
27-5 RAJ7K-027.5 5104-06030-000 Bolt, M6 x 30mm 4
27-6 RAJ7K-027.6 5105-10030-000 Socket Head Bolt, M10 x 30mm 4
27-7 RAJ7K-027.7 LJ04-01002-000 Large, Wheel Bearing 8
27-8 RAJ7K-027.8 LJ04-01004-000 Spring Support Bar 2
27-9 RAJ7K-027.9 5206-00010-000 Lock Nut, M10 4
28 RAJ7K-028 5104-10035-000 Bolt, M10 x 35mm 8
