General Specifications
Characteristics Description
Display 128 x 64 OLED with backlight
Display update for Volt Less than 2.5 times Second.
Over-range Indication on all functions Display "OL"
Operating Environment,
Relative Humidity 32°F to 122°F (0°C to 50°C) at <80%RH
Storage Environment: 32°F to 122°F (0°C to 50°C) at <80% RH
Case Construction: ABS UL 94V/0/5VA rated
Altitude: 6561.7 ft (2000m)
Dimensions: 6.4" (L) x 3" (W) x 1.4" (D)
162mm (L) x 76mm (W) x 36mm (D)
Weight: 9.4 oz (267g)
Safety: UL61010B-1, Cat III-300V
UL-1436 for AFCI, GFCI & Outlet
Accessories: Includes 1’ plug adapter, carrying case,
instruction manual. Optional alligator clip
adapter available.
Double Insulation
Instrument has been evaluated and complies with insulation category III (overvoltage cate-
gory III). Pollution degree 2 in accordance with IEC-644. Indoor use.
Measurement Specifications:
All specifications are at 23°C ± 5°C at less than 80% relative humidity.
Accuracy is state as ± ([% of range] + [counts]).
AC converter is true rms sensing.
Measurement Ranges Resolution Accuracy
Line Voltage 85.0 - 250.0 VAC 0.1V 1.0% ± .2V
Peak Line Voltage 121.0 - 354.0 VAC 0.1V 1.0% ± .2V
Frequency 45.0 - 65.0 Hz 0.1Hz 1.0% ± .2Hz
% Voltage Drop 0.1% - 99.9% 0.1% 2.5% ± .2%
Voltage Loaded 10.0 - 250.0 VAC 0.1V 2.5% ± .2V
Neutral-Ground V 0.0 - 10.0 VAC 0.1V 2.5% ± .2V
Impedance - Hot 0.00 Ω - 3.00 Ω 0.01Ω 2.5% ± .02Ω
Neutral, & Ground > 3 Ω Unspecified.
GFCI Trip Time 1mS to 6.500S counter. 1 mS 1.0% ± 2mS
GFCI Trip Current 6.0 - 9.0 mA 0.1 mA 1.0% ± .2mA
EPD Trip Current 30.0 - 37.0 mA 0.1 mA 1.0% ± .2mA
