IDEC HS5L Series

12
4-Contact / Rear Unlocking Button (Spring Lock) Package Quantity: 1
Circuit
Code
Contact Conguration Gland Port Size
Spring lock
Part No.
VA
Monitor Circuit:
Monitor Circuit:
Monitor Circuit:
Monitor Circuit:
Monitor Circuit:
Monitor Circuit:
5251
2221
11 12
4241
53 54
41 4212
21
11
22
53 54
41 4212
23
11
24
A2 A1
Monitor Circuit:
Monitor Circuit:
Monitor Circuit:
23 24
Monitor Circuit:
Monitor Circuit:
Monitor Circuit:
41
42
1211
5251
Door Monitor
(Actuator inserted)
Lock Monitor
(Solenoid OFF)
Door Monitor Circuit: 1NC,1NO Lock Monitor Circuit: 1NC,1NO
M20
HS5L-VA44LM-G
VB
Door Monitor Circuit: 1NC,1NO Lock Monitor Circuit: 2NC
M20 HS5L-VB44LM-G
VC
Door Monitor Circuit: 2NC Lock Monitor Circuit: 1NC,1NO
M20 HS5L-VC44LM-G
VD
Door Monitor Circuit: 2NC Lock Monitor Circuit: 2NC
M20
HS5L-VD44LM-G
• The contact conguration shows the status when the actuator is inserted and the switch is locked.
• Actuators are not supplied with the interlock switch and must be ordered separately.
4-Contact / Dual Safety Circuit (Spring Lock) Package Quantity: 1
Circuit
Code
Contact Conguration Gland Port Size
Spring lock
Part No.
DD
A1A2
Main Circuit:
11 12 4241
21
Main Circuit:
525122
Door Monitor
(Actuator inserted)
Lock Monitor
(Solenoid OFF)
Main Circuit: 1NC+1NC
1NC+1NC
M20 HS5L-DD44M-G
• The contact conguration shows the status when the actuator is inserted and the switch is locked.
• Actuators are not supplied with the interlock switch and must be ordered separately.
4-Contact / Dual Safety Circuit / Rear Unlocking Button (Spring Lock) Package Quantity: 1
Circuit
Code
Contact Conguration Gland Port Size
Spring lock
Part No.
DD
A1A2
Main Circuit:
11 12 4241
21
Main Circuit:
525122
Door Monitor
(Actuator inserted)
Lock Monitor
(Solenoid OFF)
Main Circuit: 1NC+1NC
1NC+1NC
M20 HS5L-DD44LM-G
• The contact conguration shows the status when the actuator is inserted and the switch is locked.
• Actuators are not supplied with the interlock switch and must be ordered separately.
HS5L Interlock Switch with Solenoid (4-Contact)
2-Contact4-ContactActuatorDimensions / Instructions
