2: P RODUCT S PECIFICATIONS
2-182 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
*1 9.3 mm when the hook is pulled out.
*2 The above drawing is for the screw fastened type. Dimensions for the push-in type are given in [ ].
Expansion Interface Module
*1 9.3 mm when the hook is pulled out.
*2 The above drawing is for the screw fastened type. Dimensions for the push-in type are given in [ ].
Digital mixed I/O modules: Screw fastened type: FC6A-M24BR1
Push-in type: FC6A-M24BR4
PID modules: Screw fastened type: FC6A-F2M1, FC6A-F2MR1
Push-in type: FC6A-F2M4, FC6A-F2MR4
39.23.8
90.0
5.0
73.0
11.4
4.0
[11.5]
*2
*1
All dimensions in mm.
Expander: Screw fastened type: FC6A-EXM2
Push-in type: FC6A-EXM24
5.0
39.23.8
90.0
73.015.2
4.0
[13.4]
*2
*1
All dimensions in mm.
