2: P RODUCT S PECIFICATIONS
2-184 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
HMI Module
*1 9.3 mm when the hook is pulled out.
*2 This dimension is 0 mm when the eject button is locked.
Cartridge Base Module
*1 9.3 mm when the hook is pulled out.
FC6A-PH1
5.0 90.0 3.9
7.374.5 73.0
66.5
119.5
148.7
4.0
*1
*2
All dimensions in mm.
FC6A-HPH1
5.0 90.0
7.343.5
4.0
73.0
93.0
*1
All dimensions in mm.
