Idegis D-10+ User Manual

1.- TECHNICAL SPECIFICATIONS
1.1. DIMENSIONS
1.2. POWER SUPPLY SPECIFICATIONS
Control: microprocessor
Self-cleaning: electronic polarity reversal
D-10+ D-18+ D-25+ D-40(+)
Input (ac) 220 Vac / 50-60 Hz
Cable (ac)
H07V/K
cable 3x1.0 mm
2
Consumption (ac)
Fuse 2 A (6x32 mm) 3 A (6x32 mm) 4 A (6X32 mm) 5 A (6X32 mm)
Output (dc) 4.5 V / 12 A 4,5 V / 22 A 4,5 V / 30 A 9 V / 25 A
Cable (dc)
H07V/K
cable 2x6 mm
2
H07V/K
cable 2x10 mm
2
Cooling Natural
4
0.8 A 1.4 A 2.0 A 2.4 A
