2.3. PH/ORP ELECTRODES
Install the pH electrode holders in the
circuit through ½” saddles (not
included with the equipment). Insert
the electrodes into their corresponding
holders. Next, tighten the holder until
the electrode is properly fixed
The electrodes must be installed in the
holder so that it is guaranteed that the
sensor located in their ends are always
submerged in the water circulating
through the pipe.
Install always the electrodes vertically
or with a maximum inclination of 40º.
2.4. ELECTRICAL CONNECTIONS
Check all the electrical connectors are well tightened to avoid false contacts and their
consequent overheating. Make the interconnection between the electrolysis cell and the
power supply according to the following scheme.
D-10+
D-18+/D-25+
10
