2.3 Ports Overview & Topologies
RS422 MASTER RS422 or RS485 cable connector to the host computer (for connector details see section 2.3.1)
RS422 HOST
This can be used as a communication interface to an access controller (for connector details
see section 2.3.1) (RS422 or RS485)
ATTENTION: No Daisychaining allowed!
Standalone Installation:
