IDENTEC SOLUTIONS iPOINT X - Technical Specifications

iPOINT X – Hardware User Manual | 18.06.2020
Copyright © 2020 IDENTEC SOLUTIONS. All rights reserved.
25
7. Technical Specifications
Communication ILR
350
technology
Operation Mode UHF Broadcast or response communication
Read Range up to 500 m
1
Compatibility i-B350, i-Q350, iQ355 Tags
Operating Frequency UHF ISM Band: 868 MHz (EU) or 920 MHz (NA)
2
Antenna / Transmit Power 2x Internal Antennas / <1mW
Communication LF
boost
Marker
Operation Mode Sends Marker ID at a predefined interval
Exciter Range up to 5m (adjustable)
1
Compatibility LF
boost
enabled tags
Operating Frequency 125kHz
Communication NFC
Antenna Integrated 13.56MHz coil (read/write)
Standards ISO/IEC 15693, ISO/IEC 14443A&B, Sony FeliCa
Status Notification NFC detection notification via Buzzer and LED
Performance
Multiple Tag handling Up to 1000 ILR Tags per read zone
Marker ID 16bit programmable
Interfaces
Data Interface Master RS422 / RS485 (Optional)
Data Interface Host RS422 / RS485 (Optional)
Status Display 5 LEDs (UHF, LF, COM, RUN & NFC)
Electrical
Power Source +15 VDC (+/-1%) - over Barrier VCL1520X
Environmental Conditions
Operating Temperature -40°C to +70°C (-40°F to +158 °F)
Storage Temperature -40°C to +85°C (-40°F to +185°F)
Humidity Up to 50%, non-condensing (open), 100% (closed)
Shock: EN 60068-2-32: Multiple drops to concrete from 1m (3ft), 5 times
EN 60068-2-29: 50G on all 3 axis, 3 times per axis
Vibrations EN 60068-2-64: noise 5 to 1000Hz, 90 minutes per axis
EN 60068-2-6: 5G, 20 sin wave cycles per axis, 5-500Hz
Standard/Certification
Europe CE (EN 300 220-1, -2, -3; EN 301 489-1,-3; EN 62368-1,
EN60950-22)
North America
FCC
Part 15 (US);
IC
RSS210
Hazardous Area (Gas) ATEX: II 2G iB IIC T4 Gb, IECEx: Ex ib IIC T4 Gb
(Mining) ATEX: I M2 Ex ib I Mb IECEx: Ex ib I Mb
Mechanical Data
Dimensions (L) 224 x (W) 214 x (T) 46 mm
Housing Colours Front: RAL 9002 Gray-White, Back: RAL 7024 Graphite-Grey
Lid:
RAL 5003 Sapphire-Blue
Enclosure Material Plastic (PC-ASA)
Enclosure Rating IP67
Weight ~2kg
Order Code
iPOINT X (IDS1002) 455990
Pole Mount Bracket (kit) 456001
1
The communication range depends on environmental conditions and national regulation limits
2
Other country frequencies are available, please contact IDENTEC SOLUTIONS
