10
Quanti-Tray Sealer PLUS User’s Manual
4. Close the sealer:
a) Lift the lever slightly to release the upper access door assembly.
The upper access door returns to the closed position.
b) Fully slide the lower access panel back into the sealer until it clips
into place.
Note: You may need to lift up on the metal insert platform while
sliding the lower access panel into place. Make sure the upper
door is flush with the face of the enclosure when you lift up on the
platform.
c) Use a standard flathead screwdriver to lock the panel, turning the
screw 90° counterclockwise. Do not
overtighten the latch. Note: Not all sealers
have a lock.
Changing fuses
Fuses are located in the fuse holder beside the power switch.
To change a fuse, turn off the sealer and unplug the power cord before opening the fuse box.
Use two 10 A, 5 x 20 mm, time-lag fuses, designed to IEC or local requirements.
4a.
4b.
4c.
