Prog. Description Page
1 Applications
1.1 General warnings 40
1.2 Machine identication 40
1.3 Warranty 41
1.4 Conditions for returns 41
1.5 Cases in which the manufacturer is not liable 41
1.6 Safety 42
1.7 Symbols 42
1.8 Glossary 43
1.9 Notes on the labels 43
2 Product presentation
2.1 Purpose 44
2.2 Composition 44
3 Layout of the manual
3.1 Information 45
4 Technical data and specications
4.1 Technical data 46
5 Unpacking and installation
5.1 Unpacking 47
5.2 Inactivity 47
5.3
Connection and installation
of the electric supply
48
5.4 Transport 48
5.5 Handling 48
5.6 Standard equipment 48
5.7 Installation and connection 49
6 Cleaning and disinfecting
6.1 Cleaning and disinfecting 50
6.2 Reinstallation and reuse 50
6.3 Destruction and disposal 50
7 Operation and use
7.1 Description of operation 51
7.2 Range of applications 51
7.3 Intended usage 51
7.4 Working limits 52
7.5 Positioning of the operator and danger areas 52
7.6 Safety features and warning indications 52
Prog. Description Page
7.7 Persistent hazards 53
7.8 Safety gear for the operator 53
7.9 Training 53
8 User instructions
8.1 Description of the safety controls 54
8.2
Description of the operations
to be carried out and functioning
54
8.3 Trial stage 55
8.4 Interrupting the running (total stop) 55
8.5 Work stoppage 55
8.6 Regulation 55
8.7 Stopping and pausing operation 56
8.8 Stopping operation 56
8.9 Emergency stop 56
8.10 Resetting conditions 56
8.11 Storage operation 56
9 Maintenance
9.1 Maintenance 57
9.2 Ordinary maintenance 57
9.3 Scheduled maintenance 58
9.4 Pressure washer test 60
9.5 Technical features 60
9.6 High pressure pump maintenance 61
9.7 Fuel pump maintenance 62
9.8 Heater maintenance 63
10 Troubleshooting
10.1 Cavitation in h.p. pumps 66
10.2 Causes and solutions 67
11 Spare parts
11.1 Maintenance conditions 70
11.2 Spare parts book 70
12 Destruction and disposal
71
13 Diagram
72
14 Declaration of conformity
73
GB
INDEX
