If hot water is available, press the MODE button
repeatedly until the HEAT icon appears on the
display. Press the UP or DOWN buttons until the
set temperature is 10 degrees above room
temperature. The hot water valve will open and the
fan will be running.
If cold water is available, press the MODE button
repeatedly until the COOL icon appears on the
display. Press the UP or DOWN buttons until the
set temperature is 10 degrees below room
temperature. The cold water valve will open and
the fan will be running.
Press the UP button until the setpoint is equal to
the room temperature. Press the Fan button
repeatedly until a single bar appears next to the
Fan icon. Confirm the fan is running on low
speed. Press the Fan button again, confirm the
fan is running on medium speed. Again, press
the Fan button, confirm the fan is running at high
speed. Press the Fan button once more, the
bars next to the Fan icon should disappear.
Press the MODE button repeatedly until the OFF
icon appears on the display. Both valves will be
closed and the fan will be off.
2-PIPE, CHANGEOVER SENSOR, NO STRIP HEAT
STEP #4
TEST OPERATION
Page 12
Turn the power on to the Fan Coil Unit and confirm
that the thermostat is programmed correctly in setup
steps #3 and #4 on page 11 of the Owner’s Manual.
