IEI Technology NOVA-945GSE User Manual

16
J_LCD_TYPE1: LVDS1 Panel Resolution Selection jumper
1-2 3-4 5-6 7-8 Resolution
OPEN OPEN OPEN OPEN LVDS1 640X480 18-bit
SHORT OPEN OPEN OPEN LVDS1 800X480 18-bit
OPEN SHORT OPEN OPEN
LVDS1 800X600 18-bit
(Default)
SHORT SHORT OPEN OPEN LVDS1 1024X768 18-bit
OPEN OPEN SHORT OPEN LVDS1 1280X1024 36-bit
SHORT OPEN SHORT OPEN LVDS1 1400X1050 36-bit
OPEN SHORT SHORT OPEN LVDS1 1400X900 36-bit
SHORT SHORT SHORT OPEN LVDS1 1600X1200 36-bit
TPM1: TPM module connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 LCLK 2 GND
3 LFRAME 4 KEY
5 LRESET 6 +5V
7 LAD3 8 LAD2
9 +3V 10 LAD1
11 LAD0 12 GND
13 SCL 14 SDA
15 SB3V 16 SERIRQ
17 GND 18 GLKRUN
19 LPCPD 20 LDRQ
