IEI Technology NOVA-945GSE User Manual

15
SATA1 & SATA2 : Serial
ATA Connectors
PIN NO. DESCRIPTION
1
GND
2 TX+
3 TX-
4
GND
5 RX-
6 RX+
7
GND
CN1, CN2: SATA1, SATA2
Power Connectors
PIN NO. DESCRIPTION
1 VCC 5V
2 GND
TV1: Video output for television
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 AGREEN_Y
3 GND 4 ARED_C
5 GND 6 ABLUE_CVBS
INV2 : 5-pin Header Inverter Connector
PIN NO. DESCRIPTION
1 N/C
2 GROUND
3 +12V
4 GROUND
5 BACKLIGHT ENABLE
