IEI Technology NOVA-945GSE User Manual

14
IDE1 : IDE Interface Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 RESET# 2 GND
3 DATA 7 4 DATA 8
5 DATA 6 6 DATA 9
7 DATA 5 8 DATA 10
9 DATA 4 10 DATA 11
11 DATA 3 12 DATA 12
13 DATA 2 14 DATA 13
15 DATA 1 16 DATA 14
17 DATA 0 18 DATA 15
19 GND 20 N/C
21 IDE REQ 22 GND
23 IOW# 24 GND
25 IOR# 26 GND
27 IDE CHRDY 28 CSEL
29 IDE DACK 30 GND
31 INTERRUPT 32 N/C
33 DA1 34 PDIAG#
35 DA0 36 DA2
37 HDC CS0# 38 HDC CS1#
39 HDD ACTIVE# 40 GND
41 VCC 42 VCC
43 GND 44 N/C
