IEI Technology NOVA-945GSE User Manual

13
MINI_PCIE1, MINI_PCIE2: PCI-e Mini Card Slots
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 PCIE_WAKE# 2 VCC3
3 N/C 4 GND
5 N/C 6 1.5V
7 CLKREQ# 8
N/C
9 GND 10
N/C
11 CLK- 12
N/C
13 CLK+ 14
N/C
15 GND 16
N/C
17 N/C 18 GND
19 N/C 20 N/C
21 GND 22 PERST#
23 PERN0 24 VCC3
25 PERP0 26 GND
27 GND 28 1.5V
29 GND 30 SMBCLK
31 PETN0 32 SMBDATA
33 PETP0 34 GND
35 GND 36 USBD-
37 N/C 38 USBD+
39 GND 40 GND
41 GND 42 N/C
43 N/C 44
N/C
45 N/C 46
N/C
47 N/C 48 1.5V
49 N/C 50 GND
51 N/C 52 VCC3
