IEI Technology NOVA-945GSE User Manual

12
JP2: COM3 RS-422/485 CONNECTOR
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 TX_422- 2 RX_422-
3 TX_422+ 4 RX_422+
5 D_485+ 6 D_485-
J8: Audio Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 LINE OUT R 2 LINE IN R
3 GND 4 GND
5 LINE OUT L 6 LINE IN L
7 GND 8 GND
9 MICIN 10 N/C
JP4 : LVDS2 Panel Resolution Selection jumper
1-2 3-4 Resolution
OPEN OPEN
LVDS2 1440X900 48-bit
(Default)
SHORT OPEN LVDS2 1024X768 24-bit
OPEN SHORT LVDS2 1366X768 24-bit
SHORT SHORT LVDS2 1280X1024 48-bit
