IEI Technology NOVA-945GSE User Manual

11
J1 : Fan Connector
PIN NO. DESCRIPTION
1 Fan Speed Detect
2 +12V
3 GND
IR1 : Infrared Interface
Connector
PIN NO. DESCRIPTION
1 VCC5
2 NC
3 IRRX
4 GND
5 IRTX
J2: Main Power Input
Connector
PIN NO. DESCRIPTION
1 VCC 5V
2 GND
3 GND
4 12V
J5: 3Pin ATX Power
Connector
PIN NO. DESCRIPTION
1 VCC 5V SBY
2 GND
3 PS ON#
JP1: configure COM3
Mode
PIN NO. DESCRIPTION
Short 1-2 RS - 232
Short 3-4 RS - 422
Short 5-6 RS - 485
KB1: PS/2 MOUSE &
KEYBOARD Connector
PIN NO. DESCRIPTION
1 VCC (+5V)
2 MDAT
3 MCLK
4 KDAT
5 KCLK
6
GND
