10
LVDS2 : LVDS Interface Connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1 GND 2 GND
3 LVDS DAP0 4 LVDS DAN0
5 LVDS DAP1 6 LVDS DAN1
7 LVDS DAP2 8 LVDS DAN2
9 LVDS CLK1+ 10 LVDS CLK1-
11 LVDS DAP3 12 LVDS DAN3
13 GND 14 GND
15 LVDS DAP4 16 LVDS DAN4
17 LVDS DAP5 18 LVDS DAN5
19 LVDS DAP6 20 LVDS DAN6
21 LVDS CLK2+ 22 LVDS CL2-
23 LVDS DAP7 24 LVDS DAN7
25 GND 26 GND
27 LCDVCC 28 LCDVCC
29 LCDVCC 30 LCDVCC
J7: CRT Connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1 L_RED 2 DDC_CLK
3 L_GREEN 4 DDC_DATA
5 L_BLUE 6 GND
7 HSYNC 8 GND
9 VSYNC 10 GND
