IEI Technology NOVA-945GSE User Manual

9
LVDS1 : LVDS Interface Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 GND
3 LVDS DAP0 4 LVDS DAN0
5 LVDS DAP1 6 LVDS DAN1
7 LVDS DAP2 8 LVDS DAN2
9 LVDS CLKA+ 10 LVDS CLKA-
11 N/C 12 N/C
13 GND 14 GND
15 LVDS DBP0 16 LVDS DBN0
17 LVDS DBP1 18 LVDS DBN1
19 LVDS DBP2 20 LVDS DBN2-
21 LVDS CLKB+ 22 LVDS CLKB-
23 N/C 24 N/C
25 GND 26 GND
27 LCDVCC 28 LCDVCC
29 LCDVCC 30 LCDVCC
INVERTER1: 5-pin Header Inverter
Connector
PIN NO. DESCRIPTION
1 LCD_BKLTCTL
2 GROUND
3 +12V
4 GROUND
5 BACKLIGHT ENABLE
