IEI Technology NOVA-945GSE User Manual

8
J9: Compact Flash Slot
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 26 N/C
2 DATA 3 27 DATA 11
3 DATA 4 28 DATA 12
4 DATA 5 29 DATA 13
5 DATA 6 30 DATA 14
6 DATA 7 31 DATA 15
7 PD_CS#1 32 PD_CS#3
8 N/C 33 N/C
9 GND 34 PDIOR#
10 N/C 35 PDIOW#
11 N/C 36 VCC_5V
12 N/C 37 IRQ14
13 VCC_5V 38 VCC_5V
14 N/C 39 CSEL
15 N/C 40 N/C
16 N/C 41 IDE_RESET
17 N/C 42 PIORDY
18 SA2 43 PDREQ
19 SA1 44 PDDACK#
20 SA0 45 IDE_ACTIVE#
21 DATA 0 46 P66DET
22 DATA 1 47 DATA 8
23 DATA 2 48 DATA 9
24 N/C 49 DATA 10
25 N/C 50 GND
