IEI Technology PCISA-6770-RS User Manual

6
DVI1 : DVI Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 DATA2- 14 Vcc
2 DATA2+ 15 GND
3 GND 16 HP_DET
4 NC 17 DATA0-
5 NC 18 DATA0+
6 DDCCLK 19 GND
7 DDCDATA 20 NC
8 NC 21 NC
9 DATA1- 22 GND-
10 DATA1+ 23 CLK+
11 GND 24 CLK-
12 NC 25 GND
13 NC
CN1: backlight inverter connector
PIN DESCRIPTION
1 NC
2
GROUND
3
BKL_POWER
4
GROUND
5
VCC
J3:External Power Connector
PIN DESCRIPTION
1
+5V
2
GROUND
3
GROUND
4
+12V
DIO1: Digital I/O
PIN DESCRIPTION PIN DESCRIPTION
1 GND 2 +5V
3 OUT0 4 OUT1
5 OUT2 6 OUT3
7 IN0 8 IN1
9 IN2 10 IN3
