IEI Technology PCISA-6770-RS User Manual

7
LVDS1 : LVDS Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 16 LVDSB_Y3-
2 GND 17 LVDSB_CLK+
3 LVDS_Y3+ 18 LVDSB_CLK-
4 LVDS_Y3- 19 LVDSB_Y2+
5 LVDS_CLK+ 20 LVDSB_Y2-
6 LVDS_CLK- 21 LVDSB_Y1+
7 LVDS_Y2+ 22 LVDSB_Y1-
8 LVDS_Y2- 23 LVDSB_Y0+
9 LVDS_Y1+ 24 LVDSB_Y0-
10 LVDS_Y1- 25 GND
11 LVDS_Y0+ 26 GND
12 LVDS_Y0- 27 VCC_LCD
13 GND 28 VCC_LCD
14 GND 29 VCC_LCD
15 LVDSB_Y3+ 30 VCC_LCD
AUDIO1
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 SPEAK(L) 2 SPEEAK(R)
3 GND 4 GND
5 LINE_OUT(L) 6 LINE_OUT(R)
7 LINEIN(L) 8 LINEIN(R)
9 GND 10 GND
11 MIC 12 GND
