J_CMOS1 : Clear CMOS Setup
J_CMOS1 DESCRIPTION
Short 1-2
(default)*
Keep CMOS Setup
(Normal Operation)
Short 2-3 Clear CMOS Setup
JLAN_PWR1:WOL setting
JLAN_PWR1 DESCRIPTION
Short 1-3 LAN 2 WOL Enable
Short 2-4 LAN 1 WOL Enable(Default)
Short 3-5 LAN 2 WOL Disable(Default)
Short 4-6 LAN 1 WOL Disable
KB1 : Internal 5-pin Header Keyboard Connector
PIN NO. DESCRIPTION
1 KEYBOARD CLOCK
2 KEYBOARD DATA
3 N/C
4 GND
5 VCC +5V
ATXCTL1 :
AT/ATX Mode Select jump
PIN NO. DESCRIPTION
Short 1-2 AT Mode
Open
(default)*
ATX Mode
ATXCTL1 : Backplane to Mainboard Connector
PIN NO. DESCRIPTION
1 GND
2 PS_ON#
3 5VSB
To Next Page
