4
Jumpers setting and Connectors
LABEL FUNCTION
J_CMOS1 Clear CMOS Jump
JLAN_PWR1 WOL Setting Jump
KB_MS1 PS/2 MOUSE & KEYBOARD connector
LAN1
LAN2
RJ45 LAN Connectors
VGA1 VGA 15-pin Female connector
USB_C6 External USB Port connector
PIDE1 IDE connector
FDD1 FDC connector
LPT1 Parallel Port connector
COM1
COM2
Internal Serial Port 10-pin connectors
USB01
USB23
USB45
Internal 6 Ports USB connectors
IR1 Infrared Interface connector
CPU_FAN1 CPU Fan Connector
ATXCTL1
AT/ATX Mode Select jump
SATA1
SATA2
SATA3
SATA4
Serial ATA connectors
DIO1 Digital I/O connector
F_PANEL1 PWR & RST Buttons & Speaker
and Indicators
J_AUDIO1 Audio Connector
KB1 Internal 5-pin Header Keyboard connector
DVI1 DVI-D connector (WSB-9454DVI Only)
CPU12V1 ATX-12V CPU Power Input connector
JSPI1 Flash SPI ROM connector
DDRII-1
DDRII-2
DDRII-3
DDRII-4
DDR2 DRAM Slots
