IEI Technology WSB-9454 Quick Installation Guide

7
COM1,COM2 :Internal Serial Port 10-pin Connectors
Connector Ports Address Interrupt
COM1 COM1 3F8 IRQ4
COM2 COM2 2F8 IRQ3
CPU12V1 : CPU POWER Input Connector
PIN DESCRIPTION PIN DESCRIPTION
1 GND 2 GND
3 +12V 4 +12V
DIO1 : Digital Input / Output Connector
PIN DESCRIPTION PIN DESCRIPTION
1 GND 2 VCC +5V
3 Output 0 4 Output 1
5 Output 2 6 Output 3
7 Input 0 8 Input 1
9 In
p
ut 2 10 In
p
ut 3
F_PANEL1 : PWR & RST Buttons & Speaker and Indicators
PIN DESCRIPTION PIN DESCRIPTION
1 PWRLED + 2 Speaker +
3 N/C 4 N/C
Power LED
5 PWRLED - 6 N/C
7 PWRBTN- 8 Speaker -
Speaker
PWRBTN
9 PWRBTN+ 10 N/C
11 HDLED+ 12 Reset +
HDDLED
13 HDLED- 14 Reset -
RESET
COM1,COM2: Internal Serial Port 10-pin Connectors
PIN DESCRIPTION PIN DESCRIPTION
1 DCD# 2 DSR#
3 RXD 4 RTS#
5 TXD 6 CTS#
7 DTR# 8 RI#
9 GND 10 NC
