IEI Technology WSB-9454 Quick Installation Guide

9
DVI1 : DVI Connector (WSB-9454DVI Only)
PIN DESCRIPTION PIN DESCRIPTION
1 Data 2- 14 VCC(+5V)
2 Data 2+ 15 GND
3 GND 16 Hot Plug Detect.
4 N/C 17 Data 0-
5 N/C 18 Data 0+
6 DDC Clock 19 GND
7 DDC Data 20 N/C
8 N/C 21 N/C
9 Data 1- 22 GND
10 Data 1+ 23 Clock +
11 GND 24 Clock -
12 N/C 25 GND
13 N/C
PIDE1: IDE Interface Connector
PIN DESCRIPTION PIN DESCRIPTION
1 RESET# 2 GND
3 DATA 7 4 DATA 8
5 DATA 6 6 DATA 9
7 DATA 5 8 DATA 10
9 DATA 4 10 DATA 11
11 DATA 3 12 DATA 12
13 DATA 2 14 DATA 13
15 DATA 1 16 DATA 14
17 DATA 0 18 DATA 15
19 GND 20 N/C
21 IDE DRQ 22 GND
23 IOW# 24 GND
25 IOR# 26 GND
27 IDE CHRDY 28 BALE – DEFAULT
29 IDE DACK 30 GND
31 INTERRUPT 32 N/C
33 SA1 34 PDIAG#
35 SA0 36 SA2
37 HDC CS0# 38 HDC CS1#
39 HDD ACTIVE# 40 GND
