9.3.4 Read input data of several IO-Link ports
34465
Register area for compact access to the input data of the IO-Link ports X01…X04: →Input Data
(→ S. 93)
The area contains the following data:
 Combined digital inputs - pin 2 / pin 4 (DI)
 Status information of the IO-Link ports
 Status information of the IO-Link devices
 Combined IO-Link input data
Observe the general rules for access to the Modbus registers (→Rules for accessing the
Modbus registers (→ S. 73))!
The parameter "Invalid Data" indicates whether the read IO-Link input data is valid.
► Also read and evaluate the corresponding status information in addition to the input data
of the ports!
Register
Contents
Access
197
Port X01…X04: Digital Input - pin 2 / pin 4 (DI)
r
198
Port X01…X04: Status Information IO-Link Ports
r
199
Port X01…X04: Status Information IO-Link Devices
r
200
Port X01…X04: Compact Input Data - IO-Link (4n Bytes)
r
r = read only
n = [2,4,8,16,32]; is determined by parameters [Process Data Length] (→Configuration Area (→ S. 88)
