Structure components:
Name Data type Description
BinOut1 BOOL Output status channel 1 (if Ch1 configuration = 2)
BinOut2 BOOL Output status channel 2 (if Ch2 configuration = 2)
BinOut3 BOOL Output status channel 3 (if Ch3 configuration = 2)
BinOut4 BOOL Output status channel 4 (if Ch4 configuration = 2)
BinOut5 BOOL Output status channel 5 (if Ch5 configuration = 2)
BinOut6 BOOL Output status channel 6 (if Ch6 configuration = 2)
BinOut7 BOOL Output status channel 7 (if Ch7 configuration = 2)
BinOut8 BOOL Output status channel 8 (if Ch8 configuration = 2)
AnaOut1_2 INT Analogue output value
(if Ch1_2 config� = 4 or 5) channel 1 or 2
AnaOut3_4 INT Analogue output value
(if Ch3_4 config� = 4 or 5) channel 3 or 4
AnaOut5_6 INT Analogue output value
(if Ch5_6 config� = 4 or 5) channel 5 or 6
AnaOut7_8 INT Analogue output value
(if Ch7_8 config� = 4 or 5) channel 7 or 8
ActCurrent1_2 WORD Actual current value [mA], channel 1 or 2
ActCurrent3_4 WORD Actual current value [mA], channel 3 or 4
ActCurrent5_6 WORD Actual current value [mA], channel 5 or 6
ActCurrent7_8 WORD Actual current value [mA], channel 7 or 8
*) The odd-numbered channels 1, 3, 5, 7 are active if the variable contains a positive value�
The even-numbered channels 2, 4, 6, 8 are active if the variable contains a negative value�
**) The actual current value can only be read if connection is made via the outputs with current monitoring
(see also wiring → 10 Technical data)�
