7 Operation
LED Colour Status Description
PWR yellow on voltage supply via USB port
flashing undervoltage or overload with voltage
supply via USB port
CH1 (C/Q) green IO-Link mode:
flashing slowly no IO-Link connection
flashing quickly preoperate state
on IO-Link connection is exchanging data
(operate state)
yellow on switching status of the digital output
CH2 (DI/D0) yellow on switching status of the digital output
Error red on error:
(short circuit, data transmission error,
overload at DIO 1 (C/Q) or DIO 2)
8 Technical data and scale drawing
