IGD TOC 635 PLUS - T635 PLUS PCB and I;O Details; T635 MICRO PCB and I;O Details

SL-014 v1.6 Page8
Document Ref: SL-014 v1.6
T635 PLUS Control Panel & 2 Wire Hub Controller PCB Features
& I/O Addresses
T635 MICRO Control Panel & 2 Wire Hub Controller PCB Features
Power in
24V DC
Power in
24V DC
Battery Backup
Display TOC-650/635 (2x8 LCD)
Display TOC-650/635 (2x8 LCD)
Fault Relay
Fault Relay
Alarm Relay 1
Alarm Relay 1
Alarm Relay 2
Alarm Relay 3
Direct Beacon-Sounder O/P
RS 485 Modbus
Ports In/Out
RS 232 Sensor Port
2 Inputs for
E-stops/Fire
1 off 2 Wire Ports Supporting 32 Addressable Devices
1 off 2 Wire Ports Supporting 8 Addressable Devices
L1
L1
L2
L2
Not
Fitted
Not
Fitted
Not
Fitted
Not
Fitted
Not
Fitted
Not
Fitted
Not
Fitted
Not
Fitted
Fitted to Controller PN TOC-635-PLUS
Fitted to Controller PN TOC-635-MICRO
Address
101
Note that addressable inputs and outputs on
the hub card and display are on Highway 0
Address
101
Address
102
Address
102
Address
103
Address
104
Address
3
Addresses
Addresses
Beacon 106
Sounder 105
Digital In ‘STOP’ Address 1
Digital In 2 ‘KEY’ Address 2
Alarm Relay 2
Address
103
