IGD TOCSIN 750 Series - T750 Control Panel PCB Features

10
T750 Control Panel & 2 Wire Hub Controller PCB Features
Power in
24V DC
Battery Connection
For Battery Backup
Ethernet
Rs485 Remote
(Modbus etc)
Display
Colour HMI
Display TOC-650 (2x8 LCD)
Fault Relay
Alarm Relay 1
Alarm Relay 2
Alarm Relay 3
Direct Beacon-Sounder O/P
Inputs for E-stops/Fire
4 off 2 Wire Ports Each supporting 32 Devices
128 Devices in Total
L1 L1 L1 L1
L2 L2 L2 L2
Notes
