16
5.3.3 Procedure
Connect according to wiring diagram (5.3.1):
• Pierce or pull out cable feedthrough and feed connection cable through.
• Check supply voltage. See name plate for permissible voltage.
• Use a shielded connection cable for the probe: e.g. LIYCY min. 0.75 mm² up to a max. length
of 50 m. LIYCY min. 1.5 m² up to a max. length of 100 m (see note).
• Use a shielded cable for the current output.
• Only connect shielding on the FARB2 control unit (terminal 12).
• After connecting to the power supply – with the device disconnected – place the hood on the
base and tighten the fastening screws.
• Fit probe according to separate assembly instructions and connect as in the wiring diagram.
When installing, check whether the cables used are UV-resistant and that UV
protection is ensured on the installation side if necessary
The cable must not come into contact with heat-conducting parts.
For aligning the probe plug to the local circumstances, the upper nut can be released ( 33.5mm). In
doing so, take care not to move the plug in the probe!! (AF24).
The contact carrier can be carefully turned into the correct position.
On refitting ensure that the seal is correctly seated! Retighten the upper nut without moving the plug in
the probe.
The connector plugs must be wired according to the wiring diagram.
