5.5 Fixing elements for mounting probes
The flanges, seals, screws and nuts listed in the table below are designed in accordance with
DIN EN 12952 und 12953.
Flanges according to DIN
PN
DN
DIN
Form
Threaded hole
Material
40
50
EN1092-1
A
according to drilling
plan 1
1.0460
63
EN1092-1
B2
100 / 160
EN1092-1
40
100
EN1092-1
A
according to drilling
plan 1,3,4,5
1.0460
63
EN1092-1
B2
100 / 160
EN1092-1
Drilling plans 1-6
Seals according to DIN
PN
DN
DIN
Material
40
50
EN 1514-1 IBC
Graphite with plain metal insert
63
2697
RSt 37-2/ 0.5 graphite
100 / 160
40
100
EN 1514-1 IBC
Graphite with plain metal insert
63
2697
RSt 37-2/ 0.5 graphite
100/160
