8
OPERATING INSTRUCTIONS
On/Off and Speed Control
The on/off and speed is controlled by the button switch.
0 = Off
1 = Low
2 = Medium
3 = High
Height Setting
• Loosen the height adjustment collar (16) by turning it anti-clockwise (g 2).
• Pull the inner pipe (15) upwards to the desired height (g 3).
• Re-tighten the collar by turning rmly clockwise (g 4).
Angle Adjustment
Switch off the fan. Slightly loosen the adjusting screw by turning it anti-clockwise.
Adjust the fan to the desired angle and then tighten the adjusting screw by
turning it clockwise.
Oscillation Adjustment
Push the oscillation control to turn on the oscillation function. Pull the oscillation
control to turn it off.
