Figure 1 ARBF & ARB2F - Overview
1 – LED lamp
2 – Telescopic front glass lifting system
3 – Wooden casing
4 – Leveling legs
5 – Stainless steel work top
6 – Stainless steel containers
7 – Side glass
8 – Serial plate
9 – Control panel
10 – Top shelf –night curtain
11 – Night curtain handle
12 – Condenser cover (DO NOT block the air louver)
ARBF4 _ 14 containers
ARBF8 _ 28 containers
ARB2F2 _ 7 containers
ARB2F-3 _ 10 containers
Figure
2 ARBF – Layout of containers
Figure 3 ARB2F - Layout of containers
