Igloo EWA 500.P - Fig.1 Construction of the Device

en
14
User manual Medium-freezing and freezing cabinets www.igloo.pl
1 – Cover (full or illuminated)
2 – Cabinet doors (full or glazed)
3 – Door grip
4 – Perforated frame strip
5 – Net shelf
6 – Cooling aggregate (freezing)
7 – Wooden platform mounted for transportation
8 – Data plate
9 – Display control panel* (temperature regulator / switches)
10 – Wind frame (when removed allows access to condenser lamellas)
11– Feet used for levelling the device
Fig. 1 Construction of the device
