IGS DIGGIN' DEEP - Connecting Touch Panel (Optional)

3
Connecting Touch Panel (Optional)
Type A
 Refer to the diagram below to connect the touch screen.
 After the connection, remember to adjust the Pin
1
of
DIP SW2
to
ON
to enable
touch mode.
Power +5V Connector
(Female)
Monitor Connector
(15PIN Female)
