Iiyama ProLite E1700S Service Manual

PLE1700S Service Manual
-13-
05/12/2006
6.6. Audio
SOLDER
SIDE
1
2
3
4
5
MUTE ACTIVE LOW
R606 used jump line,first.
R_OUT
L-OUT
DC12_AUDIO
L604
3.5X9*0.8
L603
3.5X9*0.8
C616NC/0.1u
C617
NC/0.1u
C607 470u 16V
C606 470u 16V
C601
1000u 16V
C605 220u 16V
C60222u 16V
C603 1u 50V
C604 1u 50V
L601
3.5X6X2
D601 1N4148
R61322K
S
R
RS
LS
L
P603
AUDIO INPUT (GREEN)
4
5
3
2
1
R610
10K
R611
10K
L602
3.5X6X2
R601 100K
SOCKET
P601
TO SPEAER
4
3
2
1
L-
L+
R-
R+
I601
TDA7496L
9
7
6
5
4
8
10
20
11
12 19
17
16
14
15
18
13
3
2
1
INR
VAROUT_R
VOLUME
VAROUT_L
INL
NC
SVR
GND7
STBY
MUTE GND6
OUTL
VP2
OUTR
VP1
GND5
GND4
GND3
GND2
GND1
R61222K
Q601
2SC945
R620
4K7
C615
0.1u
R602 3K9
L608
3.5X9*0.8
12V
AUDIO_STBY
Volume
