Iiyama ProLite E1700S - 12 Electrical Parts List

PLE1700S Service Manual
-32-
05/12/2006
12. ELECTRICAL PARTS LIST
When you place a parts order, be sure to indicate the following data on the order:
 Location No.
 Parts No.
 Description
LOC NO. SOURCE PART NO. DESCRIPTION SPECIFICATION REMARK
MAIN P.C.BOARD
C101 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K
C102 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K
C103 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K
C105 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K
C106 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K
C107 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K
C108 2341122096P CAP,CHIP 125'C CS 0603/COG/50V 22p J
C109 2341122196P CAP,CHIP 125'C CS 0603/COG/50V 220p J
C120 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
C121 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
C124 2336647513P CAP,MINI ELE 105'C EC 4.7u/ 50V 4*7 P=2.5
C125 2336610513P CAP,MINI ELE 105'C EC 1u/ 50V 4*7 P=2.5
C126 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
C127 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
C128 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5
C129 2341122096P CAP,CHIP 125'C CS 0603/COG/50V 22p J
C130 2341122096P CAP,CHIP 125'C CS 0603/COG/50V 22p J
C131 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
C132 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
C134 2336647513P CAP,MINI ELE 105'C EC 4.7u/ 50V 4*7 P=2.5
C135 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
C136 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
C137 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
C138 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5
C139 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
C140 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5
C141 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
C142 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
C143 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
C144 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
C145 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
C146 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5
C147 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
C148 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
C149 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5
C150 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
C151 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5
C152 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
C153 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
C156 2336347613P CAP,MINI ELE 105'C EC 47u/ 16V 5*7 P=2.5
C157 2336347613P CAP,MINI ELE 105'C EC 47u/ 16V 5*7 P=2.5
C172 2336347613P CAP,MINI ELE 105'C EC 47u/ 16V 5*7 P=2.5
C191 2336347613P CAP,MINI ELE 105'C EC 47u/ 16V 5*7 P=2.5
C199 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
C205 2336322791P CAP,MINI ELE 105'C EC 220u/ 16V 8*7 P=5.0
C206 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z
D101 RA 2364600496P DIODE,SWITCH SMD MM4148 SOD-80 GRANDE
D101 RB 2364200896P DIODE,RECT(SMD) BAS32L SOD80C PHILIPS
D101 RC 2363600696P DIODE,SWITCH RLS4148-T11 SOD-80 ROHM
D101 RD 2364601396P DIODE,SWITCH SMD 1N4148W-7-F SOD-123 DIODES
D102 RA 2364600496P DIODE,SWITCH SMD MM4148 SOD-80 GRANDE
D102 RB 2364200896P DIODE,RECT(SMD) BAS32L SOD80C PHILIPS
D102 RC 2363600696P DIODE,SWITCH RLS4148-T11 SOD-80 ROHM
D102 RD 2364601396P DIODE,SWITCH SMD 1N4148W-7-F SOD-123 DIODES
D103 RA 2364600496P DIODE,SWITCH SMD MM4148 SOD-80 GRANDE
