PLE1700S Service Manual
-6-
05/12/2006
4.2. EXPLODED VIEW PARTS LIST
Ref. No. Source Part No. DESCRIPTION SPECIFICATION Q‘TY REMARK
1F01 2024272403P FRONT BEZEL PLE1700S IIYAMA ABSHB DY-3054 1 PLE1700S-S1
1F01 2024272404P FRONT BEZEL PLE1700S IIYAMA ABSHB BLK C 1 PLE1700S-B1
1F02 2044270004P FUNCTION KEY JT178BP ABS 94HB DY-3054 1 PLE1700S-S1
1F02 2044270001P FUNCTION KEY JT178BP ABS 94HB BLACK C 1 PLE1700S-B1
1F03 2053755701P LED INDIC.-PWR JT198ZP6HR PMMA 1
2C01 2022266701P CABI BACK 178BP NO LOGO ABSHB BLK C DVI2 1
2C02 2071873500P BRACKET,FIX JT178DP SECC 0.8T WALL MOUNT 2
2C03 2071869400P BRACKET,FIX METAL PLATE 1.0MM KENSINGTON 1
5B01 2028555001P NECK JT178BP ABS 94HB BLACK C 1
5B02 2028261601P STAND JT178SP S BASE ABS 94HB BLK C 1
5B03 RA 2106658600P HINGE JT178BP 0'~20' 30~35KGF.CM HY 1
5B03 RB 2106658601P HINGE JT178BP 0'~20' 30~35KGF.CM TL 1
5B04 2084740122P SCREW,BND T+ M4*12 (BND T+) 4
5B05 2105252300P SPRING PLATE JT166DP18 P-CU T=0.2mm 1
5B06 2084730062P SCREW,BND T+ M3X6(BND T+) 1
5B07 2071880700P BRACKET,FIX JT178BP SECC 0.6T FOR STAND 1
5B08 2039819301P FOOT PAD RUBBER O20*2TMM SQUARE GRAIN 5
5F01 2071980200P METAL FITTG JT178BP/SP SECC 0.6T G/B DVI 1
5F02 2080002200P SCREW,SPE L355 M3x6 DH NICKEL-PLATED 4
5F03 2071874300P BRACKET,FIX SECC T=0.8 VE910 ACINLET 1
6B01 2084740122P SCREW,BND T+ M4*12 (BND T+) 2
6B02 2054257301P ORNAMENT JT178BP K/B HOLDER ABSHB BLK C 1
6B03 2082630062P SCREW M3X6 P=0.5 2
6B04 2084730082P SCREW,BND T+ M3X8(BND T+) 2
6B05 2082630064P SCREW M3*6 P=0.5 BLACK 4
6B06 2081440084P SCREW,(WASH) M4*8 P=0.7(TOOTH WASHER) BLACK 2
6B07 2084730084P SCREW,BND T+ M3X8(BND T+) (BLK) 2
6F01 2080003700P SCREW,SPE ISZZTER001A M3*6L MSWR17/FZMYI 6
6F02 2080003700P SCREW,SPE ISZZTER001A M3*6L MSWR17/FZMYI 2
6F04 2071676400P SHIELD PLATE JT178BP SPTE 0.3T DVI 2/B 1
6F07 2082630042P SCREW M3*4 P=0.5 2
6F08 2080004000P SCREW,SPE STAND-OFF HEX #4-40UNC H5*5*7L 2
6F09 2080004000P SCREW,SPE STAND-OFF HEX #4-40UNC H5*5*7L 2
