IKA A10 basic - Warranty Information; Technical Data

24
Technical data
Operating voltage VAC 220–240 ± 10 %
100–120 ± 10 %
Frequency Hz 50 / 60
Motor rating input W 300
Motor rating output W 240
Rated speed rpm 25000 ± 2 %
Maximum circumferential speed m/s 73
Motor brushless motor
Maximum useful volume ml 50
Maximum feed hardness Mohs 5
Maximum feed grain size mm 6 – impact milling
10 – cutting milling
Parts in contact with product stainless steel
Short time operation (KB) min 5 / 10 (5 min. ON / 10 min. OFF)
Cooling water pressure bar max. 1
Cooling water temperature °C max. 40
Timer max. min 5
Time setting accur
acy sec 1
Interval sec 15 / 1 (15 seconds ON / 1 second OFF)
Protection class according to EN 60529 IP 41
Ambient temperature °C
+ 5 ... + 40
Ambient humidity (r
elative) % 80
Operation at a terrestrial altitude m max. 2000
Dimension (W x D x H) mm 130 x 145 x 250
Weight kg 2,9
Subject to technical changes!
