16
Assembling the stand
Note: When using bath attachments with a
diameter over 180 mm, please use support
rod in conjunction with an extension. (See
“Accessories”)
)Remove screw plugs (M)
)Remove the protective cap from the support rod
)Put the washer between housing and nut
)Screw the support rod onto the device
by hand until the end stop is reached
)Use an A/f 17 spanner to tighten the
M10 nut
)Accessories should be attached using
cross sleeves
Risk of tipping!
Make sure that the center of mass of the at-
tached device does not protrude over the safe
area indicated with a dashed rectangle.
safe area
• Unpacking
- Please unpack the device carefully
- In the case of any damage a detailed report must be set immediately
(post, rail or forwarder)
• Contents of package
- Heating magnetic stirrer
- Mains cable
- Operating instructions
- Screwdriver
- Temperature sensor PT 1000
- Protection cover
• Use
- For mixing and/or heating liquids
• Range of use
- Laboratories - Schools
- Pharmacies - Universities
This device is suitable for use in all areas except industrial areas.
The safety of the user cannot be guaranteed if the appliance is operated with acces-
sories that are not supplied or recommended by the manufacturer or if the appliance
is operated improperly contrary to the manufacturer’s specifications or if the appliance
or the printed circuit board are modified by third parties.
Unpacking
Correct use
