A Drive
(maintenance-free)
: DC motor with 1-level synchronous belt drive
Environmental temp.: °C +5 to+40
Environmental humidity: % 80
Operating position:
on fixed object, tension filler facing down
Max. qty. of stirred water: ltr 10
for viscosity: LV
Clamping chuck tension range: mm 0,5 -10
Hollow shaft, internal dia.: mm 11
Extension: mm 13x160long
Housing: Al diecast, thermoplast. plastic
Dimensions excl. extension: mm (BxTxH)
80x190x175
Weight with extension and
clamping chuck: kg 2,8
Speed deviations:
Adjustment precision: % 10
When loaded: % 0 load nmax= 1600 min
-1
(nom.)
% 100 load nmax= 1200 min
-1
(nom.)
Max. speed rpm
R1342 Propeller stirrer 4fl 2 000
R1381 Propeller stirrer 3fl 2 000
R1382 Propeller stirrer 3fl 2 000
R1389 Propeller stirrer 3fl PTFE 800
R1352 Centrifugal stirrer 2 000
R1311 Turbine stirrer 2 000
R1312 Turbine stirrer 2 000
R1335 Kneading stirrer 2 000
R1330 Anchor stirrer PTFE 1 000
Associated EU guidelines
EMV guidelines: 89/336/EC
Machine guidelines: 89/392/EC
Construction in accordance with the following safety standards:
EN 61 010-1 /VDE 411-1 EN 292-1, -2
EN 50 082-1 EN 414
EN 55 014-1 IEC 1010-1
EN 60 555-2, -3 UL 3101-1
EN 60 204-1 CAN/CSA C22.2 (1010-1)
You have purchased an original IKA laboratory machine which
meets the highest engineering and quality standards.
In accordance with IKA guarantee conditions, the guarantee peri-
od is 12 months. For claims under the guarantee please contact
your local dealer. You may also send the machine direct to our
works, enclosing the delivery invoice and giving reasons for the
claim. You will be liable for freight costs.
14
RW160995EU
Viscosity
mPa · s
VLV very low viscosity 0 .......... 100
water up to
thin-flowing oil
LV low viscosity 100....... 1000
thin-flowing oil up to
thick-flowing oil
MV medium viscosity 1000.. 10000
thick-flowing oil up to
honey at approx. 20 °C.
HV high viscosity 10000 100000 honey at approx. 20 °C
up to printing inks
Permitted IKA stirrer tools
Associated standards and regulation
s
Guarantee
RW160995EU 12.11.2001 13:40 Uhr Seite 14
