Maintenance Manual C42 Series
MaintenanceManual C42-
Series_Issue_VII_18.02.2014.doc
Revison No.:1 41 from 107
Figure 47: Brake system – "Magura-BIG" brakes (since 06/2003)
Figure 48: Brake system – "Behringer" brakes (optional, from 01/2010)
brake disc
brake tubing
retention bolt
brake pad
brake shoe
Brake lever with integrated
master brake cylinder
brake disc
brake tubing
brake shoe
