iKarus C42 Series Maintenance Manual

COMCO IKARUS
Maintenance Manual C42 Series
MaintenanceManual C42-
Series_Issue_VII_18.02.2014.doc
Revison No.:1 13 from 107
2.1.2 Installation manual for Optional Items
2.1.2.1 Cowl Flap C42 Serie / C52
I. General:
Cowl flap for C42B/C and C52 allows to considerably shorten warm-up period of
the engine and to keep oil cylinder head temperature during flight operations in
optimal range of 90-110°C.
Annoying covering of the cowl flap in cold weather is a thing of the past. As a
result, optimally regulated engine temperatures as well as shortened warm-up
period of the engine minimizes fuel consumption and prolongs the life span of
the engine.
Installed temperature warning sensor (red warning light) will notify that the flap
is not opened.
II. Mechanical Installation:
- Dismantle lower cowling.
- Put on the housing of the cowl flap and fix it with 2 bolts M4 at the upper and
lower inlet lips.
Figure 7: Bolts M4
- In flight direction left, about 10 cm from below cut a slot for the Bowden cable
in the GRP sealed radiator surface of the cowling (e.g. with a small drill or
round file)
.
Figure 8: slot

iKarus C42 Series Specifications

General

Manufacturer	Comco Ikarus
Type	Light sport aircraft
Maximum takeoff weight	472.5 kg (1, 042 lb)
Engine	Rotax 912
Horsepower	80 hp (60 kW)
Cruise speed	160 km/h
Range	800 km
Service ceiling	4, 000 m
Stall speed	65 km/h
Rate of climb	5 m/s
