iKarus C42 Series Maintenance Manual

COMCO IKARUS
Maintenance Manual C42 Series
MaintenanceManual C42-
Series_Issue_VII_18.02.2014.doc
Revison No.:1 14 from 107
- Assemble lower cowling, push the Bowden cable through the cut slot, lay it
upward and push through the central firewall aperture.
Figure 9: Bowden cable
- Secure the Bowden cable with cable ties against contact with hot exhaust
parts.
Figure 10: Exhaust pipe
- Fasten the actuating lever to the hinge bar with 2 x M5 countersunk head
screws and locking nuts (left at pilot’s side).
Figure 11: actuating lever
Lead the Bowden cable under the instruments panel to the actuating lever,
adjust the length with a clamping screw and clamp it
.
Figure 12: Bowden cable

iKarus C42 Series Specifications

General

Manufacturer	Comco Ikarus
Type	Light sport aircraft
Maximum takeoff weight	472.5 kg (1, 042 lb)
Engine	Rotax 912
Horsepower	80 hp (60 kW)
Cruise speed	160 km/h
Range	800 km
Service ceiling	4, 000 m
Stall speed	65 km/h
Rate of climb	5 m/s
