iKarus C42 Series Maintenance Manual

COMCO IKARUS
Maintenance Manual C42 Series
MaintenanceManual C42-
Series_Issue_VII_18.02.2014.doc
Revison No.:1 15 from 107
- After functionality test secure the Bowden cable with cable and sleeve and
shrink tubing and cut off the supernatant Bowden cable.
III. Electrical Installation:
- Dismantel free temperature sensor at the front left cylinder.
- Mount the temperature switch, move up the sensor cable with abrasion
protection between both left cylinders and push it through the central firewall
aperture.
Figure 13: temperature switch
- In the appropriate place at the pilot’s side drill a hole for the warning light and
mount it.
Figure 14: warning light / actuating lever
- Connect the sensor cable with a cable shoe to the warning light.
- Connect the second port of the warning light with instruments " + ".
- Make functionality test with turned on main switch by removing the sensor
cable from the temperature switch and hold it against mass.
Important The light must be on.

iKarus C42 Series Specifications

General

Manufacturer	Comco Ikarus
Type	Light sport aircraft
Maximum takeoff weight	472.5 kg (1, 042 lb)
Engine	Rotax 912
Horsepower	80 hp (60 kW)
Cruise speed	160 km/h
Range	800 km
Service ceiling	4, 000 m
Stall speed	65 km/h
Rate of climb	5 m/s
